Tractor Name | Escort JOSH 335 |
---|---|
No. Of Cylinder | 2 |
Horsepower | 35 HP |
Gear Box | 6 Forward + 2 Reverse |
Price | 5 Lac* |
The Escort MPT JAWAN tractor is 35 HP tractor with 2 cylinder engine. It’s price is Rs 5 Lac*, Check it’s full specs, features and other details below.
The Company Escort MPT JAWAN who build this tractor Escort JOSH 335 is well known in this field. Escort MPT JAWAN Eicher manufactured many different models of tractor with different HP category that is listed on Tractorsprice.com. You can check their full specification, features and details
You can also check other Escort Tractor models.
Escort JOSH 335 Tractor Specification
The Escort JOSH 335 tractor engine horsepower is 35 HP and it has 2 cylinders. The max engine rated RPM is 2200. The Escort has used Oil bath type air filter and Water Cooled system for cooling.
ENGINE SPECS | DETAILS |
---|---|
NO. OF CYLINDER | 2 |
HORSEPOWER | 35 HP |
CAPACITY (CC) | |
ENGINE RATED RPM | 2200 |
COOLING | Water Cooled |
AIR FILTER | Oil bath type |
Transmission System
The transmission system of Escort JOSH 335 isConstant Mesh with Dry Single Friction Plate clutch system and it has 6 forward & 2 rear gear system. The speed range of Escort JOSH 335 is 26.9 kmph.
TRANSMISSION TYPE | Constant Mesh |
CLUTCH | Dry Single Friction Plate |
GEARBOX | 6 Forward + 2 Reverse |
WHEEL DRIVE | 2WD |
FORWARD SPEED | 26.9 kmph |
REVERSE SPEED | 10.2 kmph |
BATTERY | 12 V 75 AH |
ALTERNATOR | 12 V 36 A |
STEERING TYPE | Manual |
STEERING COLUMN | Single Drop Arm |
BREAK TYPE | Multiplate dry disc |
TURNING RADIUS | 2850 MM |
The Escort has used Multiplate dry disc system in JOSH 335. The Escort JOSH 335 has Manual steering. The max fuel tank capacity of JOSH 335 is 42 litre and Escort has used 12 V 75 AH battery in this tractor
Escort JOSH 335 PTO
PTO TYPE | Live Single Speed PTO |
---|---|
HP | |
RPM | 540 |
The tractor Escort JOSH 335 can be used for various tasks with different attatchments. But before this you need to know it’s power take off method, power so you can select right attatchment. The PTO type of Escort JOSH 335 is Live Single Speed PTO with PTO power and it’s PTO RPM is 540. Escort JOSH 335 has 1000 hydraulic lifting capacity.
Escort JOSH 335 Tractor Dimensions
Now let’s discuss about dimension of Escort JOSH 335, it’s wheel base is with ground clearance. The overall length of JOSH 335 is with total width of tractor is . This tractortotal body weight is 1760 KG.
This is a 2WD tractor with front wheel of 6.00 x 16 and rear tyre wheel of 12.4 x 28.
TOTAL WEIGHT | 1760 KG |
---|---|
LENGTH | |
WIDTH | |
GROUND CLEARANCE | |
WHEEL BASE | |
HYDRAULICS LIFTING CAPACITY | 1000 |
3 POINT LINKAGE | Automatic Depth & Draft Control |
FRONT TYRE | 6.00 x 16 |
REAR TYRE | 12.4 x 28 |
FUEL TANK | 42 litre |
Escort JOSH 335 Price & Other Details
The price of Escort JOSH 335 tractor is Rs. 5 Lac* and it has 1500 Hours Or 1 yr warranty. For current On Road price of Escort JOSH 335 and parts covered in warranty. You can contact your nearby Escort dealer or fill our Get Price form. The other accessories provided with this tractor by Escort are Tool, Toplink, Canopy, Hook, Bumpher, Drawbar.
PRICE | Rs. 5 Lac* |
WARRANTY | 1500 Hours Or 1 yr |
ACCESSORIES | Tool, Toplink, Canopy, Hook, Bumpher, Drawbar |
OTHER FEATURES | High torque backup |
If you are planning to purchase Escort JOSH 335, and if you have any query or you looking for Escort current offers and best price. Contact us, we will try to help you.
